Circular Connector MIL-DTL-5015 Style Scw Lok Cable End Plug Optional Cabl Clamp 5 Pol 3x #12/2x #4 Cont. Male Soldr. 46A/80A 500VAC/700VDC (MS3106A24-12P)(97-3106A-24-12P) |
CIRCULAR CONNECTOR MIL-DTL-5015 STYLE
Device |
Connector |
Type |
Screw Lock | Cable End Plug | Optional Cable Clamp | 5 Poles |
Highlights |
Suitable Cable Clamp/Bush - XY3057/3420-16A |
Gender |
Male |
No. of Pins |
5 |
Mates With |
XY3102A -24-12S |
Locking System |
Screw Lock |
Termination |
Solder |
Electrical Rating |
46A/80A 500VAC/700VDC |
