Product Details
Circular Connector MIL-DTL-5015 Style Screw Lock Cable End Plug Optional Cable Clamp 6 Poles 3x #16/3x #8Contacts Male Solder 13A/46A 500VAC/700VDC (MS3106A20-22P)(97-3106A-20-22P)
Circular Connector MIL-DTL-5015 Style
Additional Information
| Device | Connector |
| Type | Screw Lock | Cable End Plug | Optional Cable Clamp | 6 Poles |
| Highlights | Suitable Cable Clamp/Bush - XY3057/3420-12A |
| Gender | Male |
| No. of Pins | 6 |
| Mates With | XY3102A -20-22S |
| Locking System | Screw Lock |
| Termination | Solder |
| Electrical Rating | 13A/46A 500VAC/700VDC |
