Product Details
Compatible with Arduino Power Shield 5V/350mA with two AAA batteries and with high-efficiency DC-DC boost circuit
Overview
Power Shield is a portable offline power supply board for Arduino. Using two AAA batteries and with high-efficiency DC-DC boost circuit, this shield is the power source which can output 5V/350mA. Standard Arduino pin map makes it compatible with Iteaduino series and other Arduino compatible board.
Features
- Up to 90% high-efficiency boost circuit
- 5V/350mA output
- Power supply for external USB device with cable
Specification
- Version : 1.0
- Shield Functions : Power
- Board Size : 68.63 x 53.34 x 1.6mm
- Operation Level : Digital 5V
- Stackable : No
- Weight : 60.00g
- Operation temperature: 0degC ~ +60degC
