Product Details
CIRC CON NR SER. METAL SHIELDED IP65 SCW LOCK CABLE END RECPT 12 POLE FEMALE
Specifications
| Type | M12 Circular |
| Gender | RCP |
| Mounting | Cable Mount |
| Body Orientation | Straight |
| Number of Ports | 1 |
| Number of Contacts | 12 |
| Number of Terminals | 12 |
| Contact Gender | F |
| Termination Method | Crimp |
| Less Contact | No |
| Contact Plating | Gold |
| Maximum Current Rating (A) | 5 |
| Maximum Voltage Rating | 50VDC|25VAC |
| Minimum Operating Temperature (°C) | -40 |
| Maximum Operating Temperature (°C) | 90 |
| IP Rating | IP65 |
| Maximum Contact Resistance (mOhm) | 5 |
| Product Diameter (mm) | 28 |
| Product Length (mm) | 69 |
