OPEN FRAME MINIATURE VERTICAL PCB SWITCH MODE POWER SUPPLY
OVERVIEW
LS10-13BxxR3 series is one of Mornsun’s highly efficient green power AC-DC Converter series. They feature wide input range accepting either AC or DC voltage, high reliability, low power consumption and Class II reinforced insulation. All models are particularly suitable for industrial control, electric power, instrumentation and smart home applications which have high requirement for dimension and don’t have high requirement on EMC. For extremely harsh EMC environment, we recommend using the application circuit show in Design Reference of this data sheet
FEATURE
Ultra-wide 85 - 305VAC and 100 - 430VDCinput voltage range
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range -40℃to+85℃
Multi application, flexible layout
Compact size, high power density, green power
No-load power consumption as low as 0.1W
Output short circuit, over-current, over-voltage protection
Designed to meet IEC/EN61558, IEC/EN60335 standards
IEC/EN/UL62368 safety approval
ADDITIONAL INFORMATION
Device
AC/DC Converter
Type
Open Frame | Miniature Vertical | PCB | Switch Mode
