LMF1000-20B12

LMF1000-20B12

Regular price
Dhs. 1,046.89
Regular price
Sale price
Dhs. 1,046.89
Unit price
per
Availability
Sold out
Shipping calculated at checkout.

Metal Case Switch Mode Power Supply with Active PFC. Input: 90 ~ 264VAC/120 - 430VDC. Output 12VDC @ 80A + 5V @ 2A. Built-in Variable Speed DC Fan. (UHP-1000-12)

METAL CASE SWITCH MODE POWER SUPPLY

OVERVIEW
LMF1000-20Bxx series is one of Mornsun’s enclosed AC-DC switching power supply. It features universal AC input and at the same time accepts DC input voltage, cost-effective, low no load power consumption, high efficiency, high reliability and double or reinforced insulation. These converters offer excellent EMC performance and meet IEC/EN61000-4, CISPR32/EN55032, IEC/UL/EN62368, EN60335,EN60601, GB4943 standards and they are widely used in areas of industrial, LED, street light control, electricity, security, telecommunications, smart home. etc.
FEATURE
  • Wide range Input voltage 90 - 264VAC or 120 - 370VDC
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating ambient temperature range: -40℃ to +70℃
    (Non-condensing)
  • High reliability, efficiency up to 94%
  • Wide range of adjustable output voltage
  • Output short circuit, over-current, over-voltage protection,
    over-temperature protection
  • Support 3+1 parallel redundancy, current sharing
  • Built-in active PFC function
  • Operating up to 5000m altitude
  • Fan speed automatic adjustable
  • Safety according to IEC62368, ES/EN60601
ADDITIONAL INFORMATION
Device Power Supply
Type Metal Case | Switch Mode
Input Voltage 90 ~ 264VAC/120 - 430VDC
Output 12VDC @ 80A + 5V @ 2A
Size 190.0 x 127.0 x 40.5 mm

Datasheet Download
