Product Details
Metal Case Switch Mode Power Supply Input: 85 ~ 305VAC/120 - 430VDC. Output 15VDC @ 5A. Terminal Block Term. 4KVAC Isolation(LRS-75-15) (Metal Case 15V - 5A)
Small Outline Switch Mode Power Supply
Feature
- Universal 85 - 305VAC or 120 - 430VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- Low standby power consumption, high efficiency
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage
protection - Over-voltage class â…¢
- Operating altitude up to 5000m
Downloads
Additional Information
| Device | Power Supply |
| Type | Small Outline | Switch Mode |
| Input Voltage | 85 ~ 305VAC/120 - 430VDC |
| Output | 15VDC @ 5A |
| Size | 99.00 x 97.00 x 30.00 mm |
