DIN Rail Metal Case Three Phase Power supply with Active PFC. input 320 ~ 600VAC/450- 850VDC. Output 48VDC @ 20A

DIN Rail Metal Case Three Phase Power supply

Specifications

Universal 3x320-600VAC or 450-800VDC Input voltage
Active PFC, PF up to 0.94
Operating ambient temperature range: -30℃ to +70℃, 60 ℃ @ 100% load without
Standard DIN-Rail mounting
High efficiency, high reliability
LED indicator for output status
150% peak power lasts for 4s
Output short circuit, over-current, over-voltage, over-temperature protection
Supporting parallel (2+1 current sharing) and series
Fault alarm function, DC OK, constant current
Double-sided conformal coating, salt-spray proof
485 Communication, remote shutdown (PS ON)
Operating altitude up to 5000m
OVC Ⅲ (Safety according to EN61010)
3 years warranty
Safety according to ANSI/ISA 71.04-2013 G3
Safety according to IEC/UL/EN62368, IEC/EN61000, UL/EN61010, CISPR32/EN55032, UL508

Device	Power supply
Type	DIN Rail \| Metal Case \| Three Phase
