Series 6HsB Insert 6P+E - Size 16B - Male Screw Termination With Wire Protection 35A/400/690V = 09310062601
Series 6HsB Insert 6P+E
Specifications
Product parameters
| Inserts |
| Number of contacts |
6+PE |
| Electrical data acc. to EN 61 984 |
|
| ---Rated current |
35A |
| ---Rated voltage conductor - ground |
400V |
| ---Rated voltage conductor - conductor |
690V |
| ---Rated impulse voltage |
6kV |
| ---Pollution degree |
3 |
| ---or |
35A 500V 6kV 3 |
| Rated voltage acc. to UL |
600V |
| Insulation resistance |
≥1010Ω |
| Material |
polycarbonate |
| Limiting temperatures |
-40℃...+125℃ |
| Flammability acc. to UL 94 |
V0 |
| Mechanical working life(mating cycles) |
≥500 |
| Contacts |
| Material |
copper alloy |
| Surface |
hard-silver plated |
| Contact resistance |
≤1mΩ |
| Screw terminal |
|
| ---Wrie gauge |
1.5-6mm² |
| ---AWG |
10 |
| ---Tightening torque |
1.2Nm |
Downloads
Additional Information
| Device |
Insert |
| Type |
Series 6HsB | 6P+E | Size 16B |
