Product Details
Med. Power Sub-Mini Seal 2 Coil Latching Relay Form 1A +1BÂ (1n/o+1n/c) 24VDC 1920/1920 Ohm Coil 8A 250VAC/5A 30VDC DSP1-L2-DC24V
Overview
Features
Specification
Â
- Plastic Sealed
- Gold Plated Contacts
| Model | HFE8-24-1HDSG-L2 |
| Brand | Hongfa |
| Contact Form | Form 1A |
| Size | 20.2x11x10.4mm |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Max. Switching Current | 8A |
| Electrical Rating | 8A | 250VAC |
| Coil Power | 300mW Power |
| Coil Resistance | 1.92kΩ |
| Approvals | UL/CUL/VDE |
| Contact Material | AgNi |
