Product Details
Med. Power Sub-Mini Sealed Relay Form 1A (n/o) 12VDC 480 Ohm Coil 8A 250VAC/5A 30VDC-Gold Flash Contacts DSP1A-DC12V
Overview
Features
Specification
Â
- Plastic Sealed
- Gold Plated Contacts
| Model | HFE8-12-1H SG |
| Brand | Hongfa |
| Contact Form | Form 1A |
| Size | 20.2x11x10.4mm |
| Termination | PCB |
| Coil Rated Voltage | 12V |
| AC/DC Voltage | DC |
| Max. Switching Current | 8A |
| Electrical Rating | 8A | 250VAC |
| Coil Power | 300mW Power |
| Coil Resistance | 480Ω |
| Approvals | UL/CUL/VDE |
| Contact Material | AgNi |
