Product Details
Medium Power Mini Sealed Slim Relay Form 1A (1n/o) 7mm Contact Spacing 24VDC 2880 Ohm Coil 7A 250VAC/30VDC (277VAC/30VDC Max.) Withstands10KV Impulse
Power Mini Sealed Slim Relay
Features
- 10A switching capability
- 10kV impulse withstand voltage (between coil and contacts)
- Meets VDE 0700, 0631 reinforce insulation
- Highly efficient magnetic circuit for high sensitivity: 200mW
- Extremely small footprint utilizing PCB area
Downloads
Additional Information
| Device | Relay |
| Type | Power | Mini | Sealed | Slim |
| Contact Form | Form 1A |
| Coil Rated Voltage | 24V |
| Max. Switching Current | 7A |
| Coil Resistance | 2880Ω |
