HF36FD-012-HLT

Medium Power Sub Mini Sealed Relay Form 1C (1c/o) 7.6mm Contact Spacing 24VDC 2800 Ohm Coil 3A 250VAC/30VDC Max
Features
Provide 5A 250VAC to meet 300000 switching capability specifications
Creepage distance: 8mm (coil & contacts)
Clearance distance: NO type 4.5mm, NC type 4mm
1 Form A?1 From B and 1 Form C configurations
Subminiature, standard PCB layout
Plastic sealed and flux proofed types available
UL insulation system: Class F available
Product in accordance to IEC 60335-1 available.

Additional Information
Contact Form : Form 1C
Coil Rated Voltage : 24V
Max. Switching Current : 3A
Coil Resistance : 2800?

Downloads
HF33F-Datasheet (PDF)
