HF115FP-A230-2Z4B

High Power Mini Flux Proof Transparent Relay w/LED Indicator & Test Clip Form 2C (2c/o) 5mm Contact Spacing 24VDC 1440 Ohm Coil 8A 250VAC (440VAC Max.)
Features
1 pole 16A, 2 pole 8A , 1 CO & 2 CO contacts
5kV dielectric, Creepage distance 8 mm (coil to contacts)
Meeting VDE 0700, 0631 reinforce insulation
DC/AC coil type relay , Coil power 400mW / 0.75VA
Manual test device
Type with mechanical indicator / electrical indicator
Sockets available

Additional Information
Contact Form : Form 2C
Coil Rated Voltage : 24V
Max. Switching Current : 8A
Coil Resistance : 1440?

Downloads
HF115FP Datasheet (PDF)
