Product Details
High Power Mini Sealed Low Profile Relay Form 2C (2c/o) 5mm Contact Spacing 24VDC 1440 Ohm Coil 8A 250VAC (440VAC/300VDC Max.)- Class F Insulation
High Power Mini Sealed Low Profile
Features
- Low height: 15.7 mm
- 16A switching capability
- 5kV dielectric strength (between coil and contacts)
- Creepage distance: 10mm
- Meeting VDE 0700, 0631 reinforce insulation
- Product in accordance to IEC 60335-1 available
- Sockets available
- Plastic sealed and flux proofed types available
Downloads
Additional Information
| Device | Relay |
| Type | High Power | Mini | Sealed | Low Profile |
| Contact Form | Form 2C |
| Coil Rated Voltage | 24V |
| Max. Switching Current | 8A |
| Coil Resistance | 1440Ω |
