Product Details
Miniature High Power Relay, Form 1C, VCoil= 24V DC, IMax Switching= 10A , RCoil= 660Ω, PCB, in Vertical Case
Specifications
- Plastic Sealed
- Without Pin No. 6
- Insulation Class B
Additional Information
| Keywords | HF105F-5 Power Relay, Relay 24V 10A |
| Model | HF105F-5-024DT-1ZS |
| Device | Relay |
| Type | Power |
| Contact Form | Form 1C |
| Size Category | Mini |
| Size | 32.4x27.5x27.8mm |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Max. Switching Current | 10A |
| Electrical Rating | 10A | 240VAC |
| Coil Power | 900mW Power |
| Coil Resistance | 660Ω |
| Isolation Voltage | 4KV |
| Approvals | UL/CUL |
| Contact Material | AgCdO |
| No. of Pins | 5 Pin(s) |
| No. of Poles | 1 Pole(s) |
