Product Details
Single turn Conductive Plastic Rotary Control Potentiometer, Model : 357, Size 22.2mm dia • Turret type • 1W @ 70°C • 5kΩ • ±20% • 1 Turn 360°
Downloads
Additional Information
| Model | 357 |
| Device | Conductive Plastic Rotary Control |
| Type | Single turn |
| Size | 22.2mm dia |
| Termination | Turret type |
| Power Rating | 1W @ 70°C |
| Resistance Value | 5000Ω |
| Tolerance | ±20% |
| Tolerance Code | M |
| Element Type | Conductive Plastic |
| No. of Turns | 1 Turn 360° |
| Mechanical Life | 10 000 000 Cycles |
| Mounting Style | Bush Mount |
| Shaft Diameter | 6.35mm |
| Shaft Type | Slotted Stainless Steel |
| Shaft Length | 22mm |
