Product Details
Automotive Double Relay, 2 x Form 1C, VCoil= 12V DC, IMax Switching= 40A , RCoil= 170Ω, PCB
Overview
Features
Â
- Used for Auto door locks, Auto Windows & Sunroof
- Operating from 8V to 16V MAX
- Maximum current 2 x 40A
Specification
Â
| Contact Form | Form 1C x2 |
| Size | 26x20x16.2mm |
| Termination | PCB |
| Coil Rated Voltage | 12V |
| AC/DC Voltage | DC |
| Max. Switching Current | 40A |
| Coil Resistance | 170Ω |
