Product Details
Ezviz Battery-Powered Video Doorbell 3MP+2MP, 1/2.8” CMOS, H2.65, 2D/3D DNR, Anti-tamper Alarm, Two Way Talk, Colour Night Vision, 5200mAh Rechargeable Batt, Smart Human/Motion, Detection, WiFi Chime 72dB AC110~240VAC, Supports Micro SD Card
Battery-Powered Video Doorbell
Overview
If you want to make your front door accessible via your mobile phone, opt for the latest EP3x. Thanks to its innovative dual camera design, the EP3x allows you to see visitors at the front and packages on the ground, all at the same time even remotely. Combining both camera and doorbell functions, this 2-in-1 device enhances the security of your home as a 24/7 guardian – it can detect people and alert you to a visitor, send a video call from a delivery man, and play a pleasant ringtone from its pairing chime. 100% wire-free and battery-powered, the EP3x is almost effortless to set up and use for all.
Specifications
| Video Doorbell | |
|---|---|
| Camera Parameters | |
| Image Sensor | 1/2.8" Progressive Scan CMOS (Supports low light sensitivity) |
| Lens |
Upper camera: 2.3mm @F/2.2 , diagonal field of view 162° Bottom camera: 2.3mm @F/2.2 , diagonal field of view 155° |
| Day & Night | ICR infrared filter type ( Max: 6 meters) |
| Video Parameters | |
| Max. Resolution |
Main camera: 2K (2048 × 1296) Bottom camera: 1080p (1920 × 1080) |
| DNR | 2D / 3D DNR |
| Video Compression | H.265 / H.264 |
| Frame Rate | 15fps.Fixed frame rate |
| Radar Detection Parameters | |
| Detection Angle | 180° |
| Detection Distance | Max. 5 m (16.4 ft) |
| Sensitivity | User adjustable (high: 2.5 m, medium: 1.8 m, low: up to 1 m) |
| Interface | |
| Audio Input | Built-in high-sensitivity microphone |
| Audio Output | Built-in high-power speaker |
| Doorbell Button | Yes (1 electronic doorbell button) |
| Reset button | Yes (1 button) |
| Network Parameters | |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Functions | |
| Smart Alarm | Human shape detection Package detection |
| Anti-Tamper Alarm |
Sound and light anti-dismantling alarm (supports sending alerts to the smartphone) |
| Video Intercom | Two-Way talk |
| Wi-Fi Parameters | |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | 64 / 128-bit WEP,WPA / WPA2, WPA-PSK / WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
| Storage | |
| Local Storage (on chime) | Supports microSD card (max. 512 GB) |
| Cloud Storage | Supports EZVIZ CloudPlay Storage (subscription required) |
| General | |
| Operation Conditions | -20°C to 50°C, humidity 95% or less (non-condensing) |
| Size | 166 × 50 × 31mm (6.53 × 1.97 × 1.22 inch) |
| Battery Capacity | 5200 mAh rechargeable lithium battery |
| Power Supply | Type-C: 5V(+-10%) |
| Power Consumption | Max. 3 W |
| Chime | |
| Power Supply | AC 110 ~ 240 V |
| Wi-Fi Standard | IEEE802.11b, 802.11g, 802.11n |
| Audio Output | 72dB within 1 m |
| Storage | Supports microSD card (max.512 GB) |
| Weight | 83.6 g |
| In the box | |
| In the box | - EP3x Video Doorbell |
| - Mounting Plate | |
| - Drill Template | |
| - CH1 Chime | |
| - Screw Kit | |
| - Pin | |
| - Power Cable | |
| - Regulatory Information ×2 | |
| - Quick Start Guide | |
Downloads
Additional Information
| Device | Doorbell |
| Type | Battery-Powered | Video |
