Model Parameters

Name

C1C 1080p

Model

CS-C1C-D0-1D2WFR

Camera

Image Sensor

1/2.9" Progressive Scan CMOS

Shutter Speed

Self-adaptive shutter

Lens

2.8mm, view angle:106° (Horizontal), 130°(Diagonal)

Lens Mount

M12

Day & Night

IR-cut filter with auto-switching

DNR

3D DNR


Max. Resolution

1920 x 1080

Frame Rate

Max. 20fps; Self-adaptive during network transmission

Compression

Video Compression

H.264

H.264 Type

Main profile

Video Bit Rate

Full HD; HD; Standard. Adaptive bit rate

Auto Bit Rate

Self-adaptive

Max. Bitrate

2Mbps

Network

Smart Alarm

Motion detection

Wi-Fi Pairing

AP pairing

Protocol

EZVIZ cloud proprietary protocol

Interface Protocol

EZVIZ cloud proprietary protocol

General Features

Anti-Flicker, Dual-Stream, Heart Beat, Mirror Image, Password Protection, Watermark

Interface

Storage

Support Micro SD card (Max. 256G)

Power

Micro USB

Wi-Fi

Standard

IEEE802.11b, 802.11g, 802.11n

Frequency Range

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth

Supports 20MHz

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate

11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps

General

Requirements

- 10 - 45°C (14 - 113°F) Humidity 95% or less (non-condensing)

Power Supply

DC 5V±10%

Power Consumption

Max. 4.0W

IR Range

Max. 12 meters

Product Dimensions

64mm x 64mm x 103mm

Packaging Dimensions

123mm x 79mm x 125.5mm

Weight

96g
