Product Details
2 Way DIP Switch SMD Half-Pitch 1,27mm Gull
Specifications
- Number of Positions : 2 Position
- Switch Type : DIP
- Actuator : Flush
- Terminal Pitch : 1.27 mm
- Contact Form : SPST
- Termination Style : SMD/SMT
- Current Rating : 25 mA
- Voltage Rating DC : 24 VDC
- Series : DHN
- Contact Plating : Gold
- Life : 1000 Cycles
- Maximum Operating Temperature : + 85 C
- Minimum Operating Temperature : - 40 C
- Mounting Style : PCB Mount
- Product Type : DIP Switches
Downloads
Additional Information
| Device | Switch |
| Type | 2 Way | DIP | SMD |
