LIF480-10B48R2
LIF480-10B48R2
Regular price
Dhs. 525.44
Regular price
Sale price
Dhs. 525.44
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
DIN Rail Metal Case Slim Profile Switch Mode Power Supply with Active PFC. Input: 85 ~ 264VAC/120 - 370VDC. Output 48VDC @ 10A Hi Reliability (SDR-480-48)
SLIM PROFILE SWITCH MODE POWER SUPPLY
OVERVIEW
LIF240-10BxxR2 is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international IEC/EN/UL/BS EN 62368, UL61010 standards for EMCand safety.
FEATURE
- Universal 85- 264VAC or 120- 370VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -40℃ to +70℃
- The efficiency is up to 94.5%
- High I/O isolation test voltage up to 3000VAC
- DC OK function
- Active PFC, PF > 0.99
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
over-temperature protection, input undervoltage
protection - DIN rail TS-35/7.5 or 15 mountable
- Ultra slim design with 48mm width
- Withstand 305VAC input voltage 5S
- Safety according to IEC/UL62368, EN61558
ADDITIONAL INFORMATION
Device | Power Supply |
Type | Slim Profile | Switch Mode |
Input Voltage | 85 ~ 264VAC/120 - 370VDC |
Output | 48VDC @ 10A |
Size | W-48mm x H-132mm x D-125mm |
