Article No. 1010172200603
Industry No.
Datasheet CDGF-0,75B
SPECIFICATIONS
| Technical characteristics | |
| Material | copper alloy |
| Surface | gold plated |
| Contact resistance | ≤3mΩ |
| Wire gauge | |
| －mm2 | 0.75mm2 |
| －AWG | 18 |
| Stripping length | 8mm |
ADDITIONAL INFORMATION
| Device | Crimp Contacts |
| Type | Enhanced II | Female | Au |
