Product Details
NAND Gate Dual 4 Input 14PD(25)
Specifications
|
Logic Type
|
Counter, Decade
|
|
Direction
|
Up, Down
|
|
Number of Elements
|
1
|
|
Number of Bits per Element
|
4
|
|
Count Rate
|
5 MHz
|
|
Trigger Type
|
Positive, Negative
|
|
Voltage - Supply
|
3 V ~ 18 V
|
|
Operating Temperature
|
-55°C ~ 125°C
|
|
Mounting Type
|
Through Hole
|
|
Package / Case
|
16-DIP (0.300", 7.62mm)
|
|
Supplier Device Package
|
16-PDIP
|
Additional Information
| Device | IC |
