Product Details
Gate AND Triple 3IN +VE OC
Specifications
Electrical Characteristics
- Supply Voltage (Vcc): 4.75V – 5.25V
- Nominal Voltage: 5V
- Input HIGH (VIH): ≥ 2V
- Input LOW (VIL): ≤ 0.8V
- Output HIGH (VOH): ≥ 2.7V @ IOH = –0.4 mA
- Output LOW (VOL): ≤ 0.5V @ IOL = 8 mA
- Propagation Delay (tpd): Typical 15 ns
- Power Dissipation: Approx. 20 mW
Absolute Maximum Ratings
- Vcc: 7V
- Input Voltage: –0.5V to 7V
- Operating Temperature: 0°C to +70°C
- Storage Temperature: –65°C to +150°C
Functional Characteristics
- Number of Channels: 4
- Control Inputs: 2 (to select which channel is connected to output)
- Enable Input: 1 (active LOW typically)
- Logic Function: Analog/digital signal routing controlled by TTL logic inputs
- Output Type: Totem-pole TTL (digital signals)
Additional Information
| Device | IC |
