Product Details
Triple 3-Input NOR Gate SO14
Specifications
- Logic Type: Octal D-type flip-flop with common clock and clear
- Number of Flip-Flops: 8
- Trigger Type: Positive-edge triggered
- Clear Input: Asynchronous master reset (active LOW)
- Supply Voltage (VCC): 2 V – 6 V
- Typical Supply Voltage: 5 V
- Input Logic Level: CMOS compatible
- Output Current: ±5.2 mA (typical at 5 V)
- Propagation Delay: ~13 ns (typical at 5 V)
- Clock Frequency (max): ~30 MHz (typical, depends on VCC)
- Package Type: SOIC-20 (Surface Mount)
- Mounting Type: Surface mount (SMD)
- Operating Temperature Range: −40 °C to +85 °C
- Logic Family: HC (High-Speed CMOS)
Additional Information
| Device | Logic Gate |
