Product Details
N 80V 40V 500MA 40/120 TO105 NPN Silicon Transistor
NPN Silicon Transistor
Features
- Type: NPN silicon transistor
- Package: TO-105 metal can (small metal can, 4-lead style common in vintage electronics)
- Use: General-purpose amplifier and switching transistor
Specifications
- Polarity : NPN
- Collector-Base Voltage (Vcbo) : 80 V
- Collector-Emitter Voltage (Vceo) : 40 V
- Emitter-Base Voltage (Vebo) : ~5–7 V
- Collector Current (Ic max) : 500 mA
- Power Dissipation (Ptot) : ~0.8–1 W
- Gain (hFE) : 40–120
- Transition Frequency (ft) : ~40–120 MHz
- Package : TO-105 metal can
- Operating Temperature : Up to 150 °C
Additional Information
| CatGroup | Transistor |
| Device | Transistor |
| Type | NPN | Silicon |
