Product Details
IC Socket PRECIDIP
IC Socket PRECIDIP
Specifications
- Manufacturer: Preci-Dip
- Part Number: 223-99-308
- Product Type: IC Socket (Machine Pin / Turned Pin)
- Mounting Type: Through-Hole
- Socket Type: DIP (Dual In-Line Package)
- Number of Pins: 8 Pins
- Number of Rows: 2
- Row Spacing: 7.62 mm (0.3")
- Pin Pitch: 2.54 mm
- Contact Type: Turned (Machined) Contacts
- Contact Finish: Gold Plated
- Contact Material: Beryllium Copper
- Current Rating : 1 A
- Contact Resistance: ≤ 10 mΩ
- Insulator Material: Glass-filled Polyester
- Flammability Rating: UL94-V0
- Operating Temperature: −55°C to +125°C
- Mounting Style: PCB Through-Hole
- Compliance: RoHS Compliant
Additional Information
| Device | Socket |
| Type | IC | Socket | PRECIDIP |
