HE-016-M(17-32) - Heavy Duty Power Connectors HAN E 32P M SCREW SCREW TERMINATION

HE-016-M(17-32) - Heavy Duty Power Connectors HAN E 32P M SCREW SCREW TERMINATION

Dhs. 56.72
Dhs. 56.72
Sale Sold out
Shipping calculated at checkout.

Conquer Connections with the Robust Han E 32-Pin Male Power Connector

Engineered for demanding industrial applications, the Han E 32P M heavy-duty power connector insert delivers reliable and secure electrical connections. This male insert, part of the renowned Han E series, features 32 power contacts plus a Protective Earth (PE) connection, making it ideal for transmitting significant power and ensuring safety.

Built to Last:

  • Durable Construction: The polycarbonate (PC) housing material provides excellent impact resistance and electrical insulation, ensuring long-lasting performance in harsh environments.
  • Secure Screw Termination: Featuring robust screw terminals, this insert allows for quick and reliable wiring of conductors ranging from 18 AWG to 14 AWG.
  • High Conductivity: Silver-plated copper alloy contacts guarantee excellent electrical conductivity and minimize contact resistance, ensuring efficient power transmission.

Performance You Can Trust:

  • High Current Carrying Capacity: Rated for 16 A, this insert is designed to handle substantial power loads.
  • Reliable Voltage Performance: With a voltage rating of 500 V, it meets the requirements of various industrial power applications.
  • Positive Polarization: The design ensures correct mating within a 32B size housing/hood, preventing accidental misconnections.
Article No. 122 016 011 0002
Industry No. 09330162611
Size: 32B
Series: 32E

Datasheet HE-016-M(17-32)

Inserts
Number of contacts 32(2x16)+PE
Electrical data acc. to DIN EN 61 984
---Rated current 16A
---Rated voltage 500V
---Rated impulse voltage 6kV
---Pollution degree 3
---Pollution degree 2 also 16A 400/690V 6kV 2
Rated voltage acc. to UL/CSA 600V
Insulation resistance ≥1010Ω
Material polycarbonate
Limiting temperatures -40℃...+125℃
Flammability acc. to UL 94 V0
Mechanical working life(mating cycles) ≥500
Contacts
Material copper alloy
Surface hard-gold plated
  hard-silver plated
Contact resistance ≤1mΩ
Screw terminal
---Wrie gauge 0.75-2.5mm²
---AWG 18-14
---Tightening/Test torque 0.5Nm
---Stripping length 7.0mm
