HE-010-MS B - Heavy Duty Power Connectors HAN ES 10P MALE CAGE-CLAMP TERM
HE-010-MS B - Heavy Duty Power Connectors HAN ES 10P MALE CAGE-CLAMP TERM
Regular price
Dhs. 44.99
Regular price
Sale price
Dhs. 44.99
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
HAN ES 10-Pole Male Heavy-Duty Power Connector with Cage-Clamp Termination
Reliable power connection for demanding industrial applications. This robust Han ES insert features 10 positions plus PE (ground), a 16 A current rating, and a 500 V voltage rating. The convenient cage-clamp termination ensures quick and secure wiring of 26 to 14 AWG conductors. Built with a durable polycarbonate (PC) housing and silver-plated copper alloy contacts for optimal conductivity. Designed for use with Size 10B housings.
Article No. 122 010 012 0101
Industry No. 09330102616
Size: 10B
Series: 10ES
Datasheet - HE-010-MS BSPECIFICATIONS
| Inserts | |
| Number of contacts | 10+PE |
| Electrical data acc. to DIN EN 61 984 | |
| ---Rated current | 16A |
| ---Rated voltage | 500V |
| ---Rated impulse voltage | 6kV |
| ---Pollution degree | 3 |
| ---Pollution degree 2 also | 16A 400/690V 6kV 2 |
| Rated voltage acc. to UL/CSA | 600V |
| Insulation resistance | ≥1010Ω |
| Material | polycarbonate |
| Limiting temperatures | -40℃...+125℃ |
| Flammability acc. to UL 94 | V0 |
| Mechanical working life(mating cycles) | ≥500 |
| Contacts | |
| Material | copper alloy |
| Surface | hard-gold plated |
| hard-silver plated | |
| Contact resistance | ≤1mΩ |
| Spring terminal | |
| ---Wrie gauge | 0.14-2.5mm² |
| ---AWG | 26-14 |
| ---Stripping length | 7-9mm |
ACCESSORIES
Please Click here to view list of Accessories for size 10B
