Product Details
AM / FM Antenna Amplifier Kit
Overview
 Suits all Velleman kits requiring a regulated power supply between 5 and 12VDC, and no more than 1A.
Features
Â
- This amplifier provides 22dB gain wherever you need it. DC power supply directly or via the coax cable.
- Metal housing included.
- Gain: 22dB
- Power supply: 12V to 15V / 3mA
- Input- and output impedance: 50 - 75ohm
- Frequency range: 10MHz to 150MHz
- Dimensions: 86 x 36 x 24mm (3.4" x 1.4" x 0.9")
Specification
Â
| PCB Size | 86x36x24mm |
| Voltage | 12 to 15V |
| Current | 3mA |
| Frequency | 10-150MHz |
