Product Details
N 200V 400V 1A 30/150 TOP66
N 200V 400V 1A 30/150 TOP66
Specifications
|
Transistor Type
|
PNP
|
|
Current - Collector (Ic) (Max)
|
1 A
|
|
Voltage - Collector Emitter Breakdown (Max)
|
400 V
|
|
Vce Saturation (Max) @ Ib, Ic
|
1V @ 200mA, 1A
|
|
Current - Collector Cutoff (Max)
|
1mA
|
|
DC Current Gain (hFE) (Min) @ Ic, Vce
|
30 @ 300mA, 10V
|
|
Power - Max
|
2 W
|
|
Frequency - Transition
|
10MHz
|
|
Operating Temperature
|
150°C (TJ)
|
|
Mounting Type
|
Through Hole
|
|
Package / Case
|
TO-220-3
|
|
Supplier Device Package
|
TO-220-3
|
Downloads
Additional Information
| Device | Transistor |
