Product Details
Push Button Switch 17mm Round Brazel - Momentury100mA 50VDC (125MNA 125VAC/400mA 32VAC) IP67 1N/C Blue
Additional Information
| Device | Push Button Switch |
| Type | IP67 Non-Illuminated Momentary |
| Transition Style | Momentary |
| Termination | Solder-Lug |
| Switch Circuit | SPST-1-(0M) – without LED |
| Electrical Rating | 400mA – 32VAC | 100mA – 50VDC | 125mA – 125VAC | 500mA – 48VAC | 200mA – 50VDC | 500mA – 250VAC |
| Electrical Life | 500000 Cycles |
| No.of Poles/Pins | 2Pin |
| Bezel | 17mm Round |
| Bezel Colour | Black |
| Button Colour | Blue |
| Size | ø17.5mm |
| Mechanical Life | 1000000 cycles |
| Temperature | -30~85°C |
