Product Details
Metal Case Small Outline Switch Mode Power Supply Input: 85 ~ 305VAC/100 - 430VDC. Output 5VDC @ 5A. Terminal Block Term. 4KVAC Isolation (RS-25-05) (Metal Case 5V - 5A)
Small Outline Switch Mode Power Supply
Feature
- 85 - 305VAC or 100 - 430VDC input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- Up to 88% efficiency
- No-load power consumption < 0.5W
- High I/O isolation test voltage up to 4000VAC
- Output short circuit, over-current, over-voltage Protection
- Over-voltage class Ⅲ (designed to meet EN61558)
- Operating up to 5000m altitude
Additional Information
| Device | Power Supply |
| Type | Small Outline | Switch Mode |
| Input Voltage | 85 ~ 305VAC/100 - 430VDC |
| Output | 5VDC @ 5A |
| Size | 80.00 x 55.00 x 25.00 mm |
