LIF240-10B48R2

DIN RAIL METAL CASE SWITCH MODE POWER SUPPLY

OVERVIEW

LIF240-10BxxR2 is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international IEC/EN/UL/BS EN 62368, UL61010 standards for EMCand safety.

FEATURE

• Universal 85 - 264VAC or 120 - 370VDCInput voltage
• Accepts AC or DC input (dual-use of same terminal)
• Operating ambient temperature range: -40℃to+70℃
• High efficiency, high reliability
• DC OK function
• Built-in active PFC function
• 150% peak load output for 3 seconds
• LED indicator for power on
• Output short circuit, over-current, over-voltage, over-temperature protection
• Safety according to IEC/UL/BS EN 62368  Operating altitude up to 5000m
• OVC Ⅱ
• Indoor use
