DIN Rail Metal Case Slim Profile Switch Mode Power Supply Input: 90 ~ 264VAC/120 - 370VDC. Output 48VDC @ 1,6A. 4KVAC Isolation
Metal Case Slim Profile Switch Mode Power Supply
Feature
- Universal 90 - 264VAC or 120 - 370VDC Input voltage
- Accepts AC or DC input (dual-use of same terminal)
- Operating ambient temperature range: -30℃ to +70℃
- The efficiency is up to 90%
- High I/O isolation test voltage up to 4000VAC
- Low ripple & noise
- Output short circuit, over-current, over-voltage,
over-temperature protection - Ultra slim design: suitable for small chassis and narrow
space installation - CISPR32/EN55032 Class B compliant
- Operating altitude up to 5000m
- Meets regulates for harmonic current (IEC61000-3-2),
available for lighting application - Safety according to IEC/EN/UL62368, IEC/EN/UL60335,
- GB4943, UL508
Downloads
Additional Information
| Device | Power Supply |
| Type | Metal Case | Slim Profile | Switch Mode |
| Input Voltage | 90 ~ 264VAC/120 - 370VDC |
| Output | 48VDC @ 1,6A |
| Size | W-32mm x H-125mm x D-87.50mm |
