Product Details
Circular Connector M16 Cable Female Straight 7 Pole Screw Lock 6mm Cable Entry IP40 - 09-0326-00-07
M16 Cable Circular Connector
Downloads
Additional Information
| Device | Connector |
| Type | M16 | Cable | Circular |
| Highlights | Locking Type with threaded joint | Ground contact |
| Gender | Female |
| No. of Contacts | 7 |
| No. of Pins | 7 |
| Pin Arrangement | 300° |
| Termination | Solder |
| Size | M16x0.75 |
| Contact Resistance | <5mΩ |
| Insulator Resistance | 1013Ω |
| Cable | Cable ø4~6mm |
| Electrical Rating | 250VAC 5A |
| Degree of Protection | IP40 |
