Product Details
Medium Power Slim (6,2mm W) Mini SIL I/O Relay with Integral DIN Rail Socket Form 1C (1c/o) 24VDC 6A 250VAC/30VDC-Gold Flash Contacts (G2RV-1-S-G DC21 is Relay Fitted to Socket)
Overview
The Omron G2RV series DIN-rail mount non-latching relay has contact configuration of SPDT. It is actuated with a 24VDC coil voltage and 6A switching current. This relay has tool-free wiring with push-in terminals. It also has a test button, LED indicator and mechanical flag indicator.
Features
- Realized about 25% lower profile than conventional products, contributing to further miniaturization of the control panel.
- Push-In Plus technology are used to save wiring work in comparison with conventional screw terminals. (Wiring time is reduced by 60%* in comparison with traditional screw terminals.)
- No screw loosening means maintenance-free application, realizing high reliability
- ‘Hand-free’ structure that holds an inserted flat-blade screwdriver to achieve easier wiring work for stranded wires.
- Screw terminal is also stocked to meet the screw type needs.
- Mounted relay or solid-state relay has a plug-in terminal that is difficult to bend at the time of exchange
Specifications
| Coil Voltage | 24V dc |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Switching Current | 6A |
| Number of Poles | 1 |
| Latching | No |
| Terminal Type | Push In |
| Maximum Switching Voltage AC | 440V |
| Coil Power | 300mW |
| Maximum Switching Voltage DC | 125V |
| Length | 6.2mm |
| Depth | 78mm |
| Standards Met | CE, CULus, TUV Certification, UL 508 File No. E41643 |
| Series | G2RV |
| Isolation Coil To Contact | 4kV ac |
| Height | 90mm |
| Maximum Switching Power AC | 1.5 kVA |
| Maximum Switching Power DC | 180 W |
