Product Details
DIL Reed Relay • Form 1A • VCoil= 24V DC • IMax Switching= 500mA • RCoil= 2150Ω • PCB Std Pin L/O • without Diode
Overview
Features
Specification
| Model | 831A-7 MOD |
| Contact Form | Form 1A |
| Size | 20x8x6mm |
| Termination | PCB |
| Coil Rated Voltage | 24V |
| AC/DC Voltage | DC |
| Max. Switching Current | 500mA |
| Electrical Rating | 500mA/200VDC |
| Coil Resistance | 2150Ω |
| Isolation Voltage | 500V |
| Pin Layout | DIL |
| No. of Poles | 1 Pole(s) |
