Product Details
Video Doorphone Kit, Includes Free Indoor Ringer
Video Doorphone Kit
Specifications
- Model NO : XY WIFI SMART DOORBELL IC2
- Product Name : Low-power Intelligent WIFI Camera
- Chippest : T20Z
- WIFI : AW-NB197SM,WIFI 2.4GHz, IEEE802.11b/g/n
- PIR Distance : 10 meters
- SD Card Storage : Support Max 128G
- LED : 8pcs 850nm IR LED,10 meters IR Distance
- Indicator Light : Blue,Red
- Button : Reset Button
- Distribution network : Acoustic distribution network
- Video : TF card (10 seconds each time, can be set), support mobile phone local recording, device recording,Cloud recording
- Push Massage : Push in 1s
- Motion Detection : PIR motion detection, high sensitivity / medium / low level adjustable
Image Sensor
- Sensor : F23
- Resolution : 1920*1080
- Size : 1/2.9"
Lens
- Focal Length : 2.0MM
- Aperture : F2.4
- Perspective : Diagonal 135°
Audio
- Horn : 8Ω/1W
- MIC : Support, sound capture distance > 3 meters
- Intercom : Two-way voice intercom
- Echo cancellation : Own echo cancellation
- Howling : Howling suppression
Wake-up
- Wake-up Method : Mobile phone remote wakeup, PIR wake up
- Wake up time : <500ms
Power
- Battery Powered : 5000mAh rechargeable lithium batteries
- External Power Supply : Micro USB Port(DC5.0V）
- Working Current :260mA/3.7V
- Standby Current : 200uA/3.7V
- Standby : 6 months
- USB Charge : 10 hours full charge
Function
- Intelligent Detection : Self-owned intelligent detection algorithm to effectively reduce false positives
- Ultra low power consumption : Intelligent power saving, long standby, 5000mA original 18650 battery, normal use 8-12 months
- Simple Distribution Network : Device configuration in just 2 steps
- Quick Response : Wake up to see images up to 3 seconds, message push within 1 second
- Remote Transmission : Opening space up to 100m,with obstacle up to 30m high quality image
- Super Push Massage : The industry's first company can still receive news pushes when APP exits the background, solving the industry's pain points on the market.
- Others : Two-way voice intercom, SD card video query, Cloud recording query,device sharing, device transfer, APP online update device firmware
General
- Operating Temperature : "-10~+60 ℃
- Storage Temperature : "-20~+70 ℃
- Waterproof Level : IP66
- Mobile APP : Onecam
Downloads
Additional Information
| Device | Doorphone Kit |
| Type | Video |
