• Pure sine wave inverter
• Output power factor 1
• Built-in MPPT solar charge controller
• Selectable charging current based on applications
• Configurable AC/Solar input priority via LCD setting
• Compatible to AC mains or generator power
• Battery equalization for optimized battery performance and lifecycle

Rated Power : 1000VA/1000W
Parallel Capability : No

Input

• Voltage : 230V AC
• Selectable Voltage Range : 170-280V AC (For Personal Computers) ; 90-280V AC (For Home Appliances)
• Frequency Range : 50Hz / 60Hz (Auto sensing)

Output

• AC Voltage Regulation (Batt Mode) : 230V AC ±5%
• Surge Power : 2000VA for 5 seconds
• Efficiency (Peak) : 90%
• Transfer Time : 10ms (Personal computers) ; 20ms (Home appliances)
• Waveform : Pure sine wave

Battery

• Battery Voltage : 24V DC
• Floating Charge Voltage : 27V DC
• Overcharge Protection : 31V DC

Solar Charger & AC Charger

• Maximum PV Array Power : 600W
• MPPT Range @ Operating Voltage : 30-66V DC
• Maximum PV Array Open Circuit Voltage : 75V DC
• Maximum Solar Charge Current : 25A
• Maximum AC Charge Current : 20A
• Maximum Charge Current : 45A

Physical

• Dimensions D X W X H : 100 X 272 X 355
• Net Weight (kgs) : 7.0kg

Environment

• Humidity : 5% to 95% relative Humidity (Non-condensing)
• Operating Temperature : 0°C to 55°C
• Storage Temperature : -15°C to 60°C
