Product Details
Signal Sub Mini Seal 2 Coil Latching Relay Form 2C (2c/o) 5VDC 125/125 Ohm Coil 1A 30VDC 0,5A 125VAC (250VAC Max.) - Gold Flash Contacts
Downloads
Additional Information
| Device | Relay |
| Type | Telecom |
| Contact Form | Form 2C |
| Size Category | Submini |
| Coil Rated Voltage | 5V |
| AC/DC Voltage | DC |
| Max. Switching Current | 1A |
| Electrical Rating | 1A/30VDC |
| Coil Power | 200mW Power |
| Coil Resistance | 125Ω |
| Contact Material | Ag/Au clad |
| Coil Feature | Polarized |
| No. of Pins | 10 Pin(s) |
| No. of Poles | 2 Pole(s) |
