Product Details
2KW High Frequency Pure Sine Wave Inverters for RV. Rated Battery Voltage: 12VDC. Rated Output Power: 2,000W. Rated Output Voltage: 220/230(Default)/240VAC(±3%)
2KW High Frequency Pure Sine Wave Inverters
Specifications
|
ITEM |
IC12-2kW |
|
Rated Battery Voltage |
12Vdc |
|
Battery Voltage Range |
10.8～16Vdc |
|
Rated Output Power |
2,000W |
|
Peak Power |
4,000W |
|
Rated Output Voltage |
220/230(default)/240Vac(±3%) |
|
Output Frequency |
50/60Hz |
|
Output Waveform |
Pure Sine Wave |
|
THD |
THD<4%（Resistive Load） |
|
Power Factor |
0.2-1（Load Power≤Continuous Output Power） |
|
Rated Output Efficiency |
>89% |
|
Max. Output Efficiency |
>92%(30% Load) |
|
Standby Current (OFF mode) |
<0.2A |
|
0 Load Ourrent (ON mode) |
<1.0A |
|
Dimensions |
409*249*120mm |
|
Weight |
6.0kg |
|
Noise |
<60dB |
|
Cooling Method |
Neutral Cooling+ Intelligent Fan |
|
IP Grade |
IP20 |
|
Ambient Temperature |
-20°C～60°C |
|
Certificates |
CE、ROHS、IEC62109-1/2、EN61000-6-2/4 |
Downloads
Additional Information
| Device | Inverters |
| Type | 2KW | High Frequency | Pure Sine Wave |
