Product Details
ø20mm Radial Power NTC Thermistor for Limiting Inrush Current with R25°C= 2.5Ω, I25°C= 9A, ±20% Tolerance
Overview
Features
Â
- RoHS & Halogen Free (HF) compliant
- Radial lead resin coated
- High power rating
- Wide resistance range
- Cost effective
- Operating temperature range :
- Agency recognition: UL / cUL / TUV / CSA / CQC
Specification
Â
| Size | ø20mm |
| Termination | Radial |
| Tolerance | ±20% |
| Tolerance Code | M |
| Max Steady State Current @25 degC | 9A |
| Zero Power Resistance @ 25 degC | 2.5Ω |
