Product Details
IP67 Non-Illuminated Latching Push Button Switch • Form : SPST-0-(1) • 17mm Round Black Bezel • Yellow Button • Solder-Lug
Overview
Features
Specification
| Transition Style | Momentary |
| Termination | Solder-Lug |
| Switch Circuit | SPST-0-(1) |
| Electrical Rating | 100mA – 24VDC | 2A – 125VAC |
| Electrical Life | 500000 Cycles |
| No.of Poles/Pins | 2Pin |
| Bezel | 17mm Round |
| Bezel Colour | Black |
| Button Colour | Yellow |
| Size | ø17.5mm |
| Mechanical Life | 1000000 cycles |
| Temperature | -30~85°C |
