LS10-13B09R3

LS10-13B09R3

Dhs. 15.33
Dhs. 15.33
Sale Ausverkauft
Versand wird beim Checkout berechnet

Open Frame Miniature Vertical PCB Switch Mode Power Supply Input: 85 ~ 305 VAC/100 - 430 VDC. Output 9VDC @ 1,1A



OPEN FRAME MINIATURE VERTICAL PCB SWITCH MODE POWER SUPPLY

OVERVIEW
 LS10-13BxxR3 series is one of Mornsun’s highly efficient green power AC-DC Converter series. They feature wide input range accepting either AC or DC voltage, high reliability, low power consumption and Class II reinforced insulation. All models are particularly suitable for industrial control, electric power, instrumentation and smart home applications which have high requirement for dimension and don’t have high requirement on EMC. For extremely harsh EMC environment, we recommend using the application circuit show in Design Reference of this data sheet

FEATURE
  • Ultra-wide 85 - 305VAC and 100 - 430VDCinput voltagerange
  • Accepts AC or DC input (dual-use of same terminal)
  • Operating ambient temperature range -40℃to+85℃
  • Multi application, flexible layout
  • Compact size, high power density, green power
  • No-load power consumption as low as 0.1W
  • Output short circuit, over-current, over-voltage protection
  • Designed to meet IEC/EN61558, IEC/EN60335 standards
  • IEC/EN/UL62368 safety approval
ADDITIONAL INFORMATION
Type Open Frame | Miniature Vertical | PCB | Switch Mode
Input Voltage 85 ~ 305 VAC/100 - 430 VDC
Output 9VDC @ 1,1A
Size 32.00 x 17.20 x 15.05 mm

Datasheet Download
