Product Details
DIN Rail Plastic Case Slim Profile Switch Mode Power Supply Input: 90 ~ 264VAC/127 - 370VDC. Output 12VDC @ 1,25A 4KVAC Isolation
Slim Profile Switch Mode Power Supply
Feature
- Universal 85-264VAC (277VAC available) or 120-370VDC (390VDC available) input voltage
- Accepts AC or DC input (dual-use of sameterminal)
- Operating ambient temperature range -40℃to+70℃
- High I/O isolation voltage up to 4000VAC
- Industrial-grade design
- OVC III (EN61558-1 standards)
- Low standby power consumption, high efficiency
- Low ripple & noise
- Output short circuit, over-current, over-voltageprotection
- DIN rail TS35X7.5/ TS35X15 mountable
- Safety according to UL/IEC62368, IEC/EN61010, IEC60335,IEC/EN61558
Downloads
Additional Information
| Device | Power Supply |
| Type | Slim Profile | Switch Mode |
| Input Voltage | 90 ~ 264VAC/127 - 370VDC |
| Output Current | 12VDC @ 1,25A |
| Size | W-17,5mm x H-90mm x D-58mm |
