SLIM PROFILE SWITCH MODE POWER SUPPLY

OVERVIEW

LI120-20B12R2S is Mornsun AC-DC converter series featuring a cost-effective, energy efficient green power supply solution for standard DIN-rail mounting. The products offer a high level of stability and immunity to noise for industrial control equipment, machinery, and other industrial equipment in a variety of harsh environments. These light weight AC-DC converters have an extremely compact design and the standard rail installation for space saving. With good EMC performance, compliant with international UL61010, UL508, EN/BS EN 62368 standards for EMC and safety.

FEATURE

• Universal 90 - 264VAC or 127 - 370VDCInput voltage
• Accepts AC or DC input (dual-use of same terminal)
• Operating ambient temperature range: -20℃to+60℃
• High I/O isolation test voltage up to 4000VAC
• Low ripple & noise
• Output short circuit, over-current, over-voltage, over-temperature protection
• DIN rail TS-35/7.5 or 15 mountable
• Ultra slim design: suitable for small chassis and narrow space installation
• Safety according to UL61010, UL508
