Product Details
Ø 23mm DPST - Round Bezel Push Button Switch with On/Off Lamp Latch; Rating : 10A-250VAC, Fast-On : 4.75Typ in Green (illu)
Overview
Features
Specification
Â
| Transition Style | Latching |
| Actuator Style | Round Flat Push Button |
| Operation Type | Latch |
| Termination | Solder-Lug |
| Switch Circuit | DPST |
| Voltage Rating | 250V |
| Voltage Type | AC |
| Current Rating | 10A |
| Contact Rating | 10A @ 250VAC |
| Bezel | 23mm Round |
| Bezel Colour | Black |
| Button Colour | Green |
| Size | Ø 23mm |
| Mechanical Life | 30000 cycles |
| Temperature | -30~85°C |
