Product Details
EZVIZ Smart Home WiFi Camera PAN & Tilt 4MP Triple-Lens 2.8mm~ 6mm~12mm 2K+, 30m Night Vision, 3D DNR, WDR, AI-Powered Human/Shape Detection, Two-Way Talk, 12×Zoom, Siren/Strobe Light, Auto Zoom, H2.65, 360° Panoramic View, 12V1.5A, IP67
Smart Home WiFi Camera
Overview
The H80f Multi, EZVIZ‘s first triple-lens outdoor camera, is designed to provide
exceptional outdoor security with unseen professionalism. The integrated capability
of three powerful 2K+
lenses allows the camera to capture a wide view and close-up
details simultaneously, supported by an incredible, non-blurry 12-times zoom. Its
embedded AI can effectively detect and lock on both people and vehicles to record an
ongoing activity from left to right, while you receive more informative mobile alerts
accompanied by double snapshots of both the visitor and the car.
Specifications
| Camera | |
|---|---|
| Image sensor | F1.6@1/3" Progressive Scan CMOS |
| Shutter Speed | Self-adaptive shutter |
| Lens | 4mm, view angle: 90°(Diagonal), 80° (Horizontal), 43°(Vertical) |
| Lens Mount | M12 |
| Day & Night | IR-cut filter with auto-switching |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Compression | |
| Video Compression | H.264/H.265 |
| Video Bit Rate | Adaptive bit rate. |
| Image | |
| Max. Resolution | 1920 × 1080 |
| Frame Rate | Max:25fps; Self-Adaptive during network transmission |
| Network | |
| Smart Alarm | Motion Detection, Human Detection, Human Tracking, Noise Detection, Auto Patrol |
| Wi-Fi Pairing | AP Paring |
| Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface Protocol | EZVIZ Cloud Proprietary Protocol |
| Interface | |
| Storage | Micro SD card slot (Max. 512G) |
| Power | Type-C |
| Wired Network | RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
| Wi-Fi | |
| Standard | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth | Supports 20MHz |
| Security | WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate | 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps |
| Output Power(EIRP) | 19 dBm |
| Antenna Gain | 1.9 dBi |
| General | |
| Operating Conditions | -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing) |
| Power Supply | DC 5V/1A |
| Power Consumption | Max. 5W |
| IR Range | Max. 10 meters (32.81ft) |
| Dimensions | 88mm x 88.2 mm x 119mm (3.46” x 3.47” x 4.69”) |
| Packaging Dimensions | 103mm x 103mm x 168mm (4.06” x 4.06” x 6.61”) |
| Bare Weight | 218g (0.48lb) |
| In the box | |
| In the box | - Camera |
| - Power Adapter | |
| - Power Cable | |
| - Drill Template | |
| - Mounting Plate | |
| - EZVIZ Screw Kit | |
| - Regulatory Information | |
| - Quick Start Guide | |
Downloads
Additional Information
| Device | Camera |
| Type | Smart Home | WiFi |
